Abfallschüttung waste
Trennvlies separation geotextile
Drainagerohr drainage pipe
Mineralische Entwässerungsschicht (> 0,3m) mineral drainage layer
Trennvlies separation geotextile
Mineralische Schutzschicht (< 0,1m) mineral protective layer
Schutzvlies (> 1.200 g/m² PEHD) protective layer
Kunststoffdichtungsbahn (2,5 mm PEHD) plastic sealing strip
Mineralische Dichtung (0,75 m) mineral sealing
GEologische Barriere (Auelehm, > 0,50m) geological barrier (alluvial clay)
Aufnahmedatum: 02.08.2014
Stadtteil: Bürrig
